A 2.5D pocket milling is extensively used in aerospace, shipyard, automobile, dies and molds industries. In machining of 2.5D pockets, directional parallel tool-path and contour parallel tool-path are widely used. However, these tool paths significantly limit the machining efficiency. In the present work, an attempt has been made to generate a spiral tool path for machining of 2.5D star-shaped pocket for improving machining efficiency. The spiral tool path is developed using second order elliptic partial differential equation (PDE) and it is free from sharp corners inside the pocket region. Further, the implementation of proposed method is presented on complex non-star-shaped polygon, pocket bounded by free-form curve and pocket with island.
The shape of pocket geometry, tool path strategy and various machining parameters (speed, feed rate and depth of cut) affect machining performance. However, the effect of the shape of a pocket geometry and tool path strategy on the performance of pocket machining is scarcely reported. Hence, an attempt has been made to investigate the effect of aspect ratio, feed rate and tool path strategies (zig-zag, spiral and contour parallel) on tool path length, cutting time, percentage utilization of a tool and average surface roughness in machining of AISI 304 stainless steel using design of experiments (DOE).
From the findings of above experimental investigation, it was anticipated that there is a need to develop a method (or technique) for comparing different pocket geometry quantitatively and predict the effect of pocket geometry on pocket machining. A novel approach is reported for quantitative comparison of different pocket geometries using a dimensionless number, Divyang Number (DN). The concept and formula of DN are developed and DN is calculated for various pocket geometries. The guidelines for comparing pocket geometries based on DN and PUT (percentage utilization of tool) are reported. The results show that DN can be used to predict the quality of tool path prior to tool path generation. Further, an algorithm to decompose pocket geometry (parent geometry) into sub-geometries is developed that improves the efficiency of spiral tool path for bottle-neck pockets using HARI Number. The results indicate that decomposing pocket geometry with the new algorithm improves HARIN and removes the effect of bottle-necks. Furthermore, the algorithm for decomposition is extended for pockets that are bounded by free-form curves.
Table of Contents
Abstract
List of Figures
List of Tables
1 Introduction
1.1 Background and Motivation
1.2 Organization of Thesis
2 Literature Review
2.1 Introduction
2.2 Basic Terminologies Associated with Pocket Machining
2.3 Tool Path Requirements for High Speed Pocket Machining
2.4 Organization of the Literature Review
2.5 Noteworthy Literature Reviews
2.6 Various Types of Pockets and Pocket Machining
2.7 Conventional Tool Path Strategies
2.7.1 Directional Parallel
2.7.2 Contour Parallel (Boundary Parallel or Offset) Tool Path
2.7.3 Space Filling Curves
2.8 Corner Machining Tactics
2.9 Advance Tool Path Strategies for HSM
2.9.1 Mapping Based Approaches for Tool Path Generation
2.9.2 Medial Axis Transform Based Method for Tool Path Generation
2.9.3 Clothoidal Spiral Tool Paths
2.9.4 Spiral Tool Paths Based on the Solution of PDE
2.9.5 Trochoidal Tool Paths
2.9.6 Interpolating Tool Paths Based on Bezier, B-spline and NURBS
2.9.7 Miscellaneous Tool Path Planning Strategies
2.10 Current Status of Development in Tool Path Strategies
2.11 Summary Table
2.12 Observations
2.13 Objective of Present Research
3 Spiral Tool Path Based on PDE and NURBS
3.1 Introduction
3.2 Methodology
3.2.1 The Algorithm for Generating Spiral Tool Path for Star-Shaped Polygon Using PDE
3.3 Extending the Method for Non-star-shaped Polygon and Free-form Curves
3.4 Results and Discussion
3.4.1 Effect of Mesh Size on Tool Path.
3.4.2 Effect of Permissible Error and Number of Degree Steps
3.5 Conclusions
4 Study of Elliptical-pocket Machining
4.1 Introduction
4.2 Experimental Details
4.2.1 Tool Path Strategy and Pocket Geometry
4.2.2 Tooling Details and Machining Conditions
4.3 Experimental Plan Procedure
4.4 Results and Discussion
4.4.1 Tool Path Length
4.4.2 Cutting Time
4.4.3 Percentage Utilization of a Tool (PUT)
4.4.4 Average Surface Roughness (Ra)
4.5 Conclusions
5 Quantitative Comparison of Pocket Geometries and Pocket Decomposition
5.1 Introduction
5.2 Dimensionless Number (DN) for Comparing Pocket Geometries
5.2.1 Analogy of Reynolds Number
5.2.2 Percentage Utilization of a Tool (PUT) as a Measure of Effectiveness of Spiral Tool Path
5.2.3 The Concept of Dimensionless Number (DN)
5.2.4 Various Ratios and Their Effects
5.2.5 Dimensionless Number, DN
5.2.6 Modified DN for Spiral Tool Path (DNspiral)
5.3 Results and Discussion
5.4 Pocket Decomposition
5.4.1 Decomposition of a Polygon Geometry
5.5 Free-form Pocket Decomposition
5.6 Decomposition of a pocket with an island
5.7 Conclusions
6 Study of speed, feed and step-over in pocket milling
6.1 Introduction
6.2 Experimental Investigation
6.2.1 Selection of Process Variables, Responses, Workpiece/Tool Material and Tool Path Strategy
6.3 Experimental Setup
6.3.1 Fixture Design
6.3.2 Designing the Experiments
6.3.3 Selection of Sampling Frequency
6.4 Results and Discussion
6.4.1 Cutting Time
6.4.2 Surface Roughness
6.4.3 A Method of Analysing Cutting Forces
6.5 A Crucial Test Before linear Cutting Forces Experiments
6.6 Conclusions
7 Overall Results and Discussion
7.1 Overall Results and Discussion
8 Conclusions
8.1 Conclusions
8.2 Scopes of Future Research
9 References
Appendix 1: Underestimation of Machining Time ( )
Appendix 2: Chemical Analysis of AISI P20
Appendix 3: Certificate of Experimental Readings
Appendix 4: Specifications of Vertical Machining Centre PX10.
Appendix 5: Specifications of KISTLER 9272
Appendix 6: List of Research Publication based on Ph.D. work
Disclaimer
This book is largely based on a Ph.D. thesis entitled “Tool Path Development for CNC Pocket Machining Using Partial Differential Equation and NURBS Curve” submitted in partial fulfilment of the requirements for the award of the degree of Doctor of Philosophy by Patel Divyangkumar Dharmendra and supervised by Dr. D. I. Lalwani (Asociate Professor) at Department of Mechanical Engineering, Sardar Vallabhbhai National Institute of Technology, Surat - 395 007, Gujarat, India.
COPYRIGHTS @ 2018
This document is copyrighted material. Under copyright law, no part of the document may be produced without the expressed written permission of the author and the supervisor.
Acknowledgment
I take this opportunity to express my sincere gratitude to the all-pervading Supreme Personality of Godhead, Lord Sri Krishna who is seated in everyone’s heart as the super- soul, from whom comes all knowledge, remembrance and forgetfulness, who is the reservoir of all pleasure, without whose sanctions not even a blade of grass can move, for providing me sufficient strength, knowledge and inspiration to carry out this work.
I would also like to express my deep gratitude to Dr. D. I. Lalwani, Associate Professor, in Mechanical Engineering Department, SVNIT, Surat for his valuable guidance, motivation, co-operation with an encouraging attitude. He revised my manuscripts with me, word by word. Even though at many times I felt that it was enough and would like to submit, he patiently went through my lengthy manuscripts, uncovering problems here and there, refining the manuscripts to perfect art pieces. He is the person whom I am infinitely indebted
I take this opportunity to express my sincere gratitude to the authorities of SVNIT and the Department of Mechanical Engineering for giving me this opportunity to study and avail the facilities of this Institution.
I am also very much thankful to Prof. Vijay Chaudhary (HOD, Mechanical Department, CHARUSAT), for allowing me to use CNC machine and Kistler dynamometer for force measurement. I am also very much grateful to Dr. Harshit K. Dave for kindly allowing me to use laboratory facility. Also, I would like to thank Mr. Hiren Patel, Mr. Mrugesh Patel, Mr. Umesh Thakkar, Mr. Mukesh Patel and Akash Panday for their help.
I would also like to express my sincere gratitude to Prof. A. K. Shukla, Prof. H. K. Raval, Prof. K. P. Desai and Prof. A. A. Shaikh for giving their valuable time and suggestions at every stage of my research. During our M.tech, A. A. Shaikh Sir asked the students “Is it possible to develop and the equation of a polygon?” This statement gave me a concept that something like this is also possible. Later, I developed an equation of polygon in polar form and used it for generating spiral tool path.
I am also very much thankful to Dr. J. V. Menghani for asking me a question in my credit seminar that “Is there any method or technique or number for comparing different types of pockets?” At that time I gave some convincing reply but later that question triggered the concept of Dimensionless Number (DN) for quantitatively comparing different pockets.
I am also very much in debt to H. G. Caitanya Avatar Das and H. G. Ishana Gaura Das and all my friends for kindly allowing me to stay in their room whenever I came to Surat for my Ph.D. work. I would also like to thank Vishwambhara Das for providing nice prasadam during my stay in Surat. I am also very much thankful to Principal of SVIT, Dr. J. V. Deshkar and my colleagues, namely, Dr. P. V. Ramana, Dr. P. B. Tailor, S. P. Patel, D. S. Shah, Sekar S., Hardik Dodiya and the entire staff of Mechanical Engineering Department, SVIT for their overall support and encouragement.
I am also very much thankful to my wife Nidhi Gaurangi Devi Dasi and my sons Madhusudana and Baladeva for tolerating, and co-operating me during my Ph.D. work. I am also very much in debt to my parents and family members, (namely Nimesh Patel and family, Prakash Patel and family, Mukesh Patel and family, Sankar H. Patel and family) for their support in various ways. The list is endless but I am thankful to everyone who helped me directly or indirectly. I pray that all of them may achieve the ultimate benefit, supreme destination and the worshipable object of their life, i.e., shelter at the lotus feet of Sri Sri Radha and Krishna.
Dr. D. D. Patel
Abstract
A 2.5D pocket machining is widely used in aerospace, shipyard, automobile, dies and mold industries. In machining of 2.5D pockets, conventional tool path strategies, such as directional parallel tool path and contour parallel tool path, are widely used. However, these tool paths significantly limit the machining performance in terms of machining time, surface finish and tool wear because of repeated machining direction alteration, stop-and-go motion, sharp velocity discontinuity, and frequent repositioning, retraction, acceleration and deceleration of a tool.
To overcome the above-mentioned problems of conventional tool path strategies, an attempt has been made to generate a spiral tool path for 2.5D pocket machining. The spiral tool path is developed using second order elliptic Partial Differential Equation (PDE) and NURBS and it is free from sharp corners inside the pocket region. The spiral tool path begins as a smooth spiral in the pocket interior then progresses outward and finally morphs to the pocket boundary. The algorithm for the spiral tool path is coded in MATLAB® for pre-processing, solving and post-processing of elliptic PDE. The successful generation of spiral tool path depends on various algorithm parameters such as mesh size, permissible error and number of degree-steps. The effect of these parameters on spiral tool path generation is studied and the best values are reported. Further, the developed algorithm is implemented and experimentally validated on pockets that are bounded by a non-star-shaped polygon with bottle-necks, free-form curve and pocket with an island.
The shape of pocket geometry, tool path strategy and various machining parameters (speed, feed rate and depth of cut) affect machining performance. A large amount of the literature related to pocket machining deals with tool path generation and the effect of various machining parameters. However, the effect of the shape of a pocket geometry and tool path strategy on the performance of pocket machining is scarcely reported. Hence, an attempt has been made to investigate the effect of aspect ratio (i.e., changing the shape of a pocket), feed rate and tool path strategies (zig-zag, spiral and contour parallel) on tool path length, cutting time, percentage utilization of a tool and average surface roughness in machining of AISI 304 stainless steel using design of experiments (DOE). A novel concept of Percentage Utilization of a Tool (PUT) is developed to study the effect of tool path strategy and aspect ratio (shape of pocket geometry). It was found from the experimental investigation that the spiral tool path suffers a problem of over machining, i.e., increased tool path length because of squeezing of tool path in a narrow or a bottle-necked region.
From the findings of above experimental investigation, it was anticipated that there is a need to develop a method (or technique) for comparing different pocket geometry quantitatively and predict the effect of pocket geometry on pocket machining. A novel approach is reported for quantitative comparison of different pocket geometries using a dimensionless number, ‘DN’. The concept and formula of DN are developed and DN is calculated for various pocket geometries. The guidelines for comparing pocket geometries based on DN and PUT are reported. The results show that DN can be used to predict the quality of tool path prior to tool path generation.
Further, an algorithm to decompose pocket geometry (parent geometry) into sub-geometries is developed that improves the efficiency of spiral tool path for bottle-neck pockets (or multiple-connected pocket). The algorithm uses another dimensionless number ‘HARIN’ to compare parent pocket geometry with sub-geometries; HARI is the abbreviation of ‘Helps in Appropriate Rive-lines Identification’ and suffix ‘N’ stands for a number, hence it is spelled as ‘HARI number’. The developed algorithm is particularly useful where the region of the bottle-neck cannot be visualized easily. The results indicate that decomposing pocket geometry with the new algorithm improves HARIN and removes the effect of bottle-necks. Furthermore, the algorithm for decomposition is extended for pockets that are bounded by free-form curves.
In addition, experimental investigation of speed, feed and step-over on cutting time, surface roughness and cutting forces in the pocket machining of AISI P20 is carried out using spiral tool path. Also, a new method to select the sampling frequency of dynamometer and analysis the cutting force in machining of pocket using spiral tool path are reported.
